CMI 400TPH Portable Counterflow Drum Plant

DESCRIPTION:  Complete upgraded C.M.I. Portable Counterflow Drum Plant. Features of this plant include the following:

· Portable C.M.I. Model PAB-432 - Four (4) Bin 10’ x 14’ Cold Feed System with 30” wide feeders, 5 HP shaft mounted drives and a nominal 30” wide integral collecting conveyor with bi-folding head section. This cold feed system is also equipped with self-storing folding support pads to grade, self-contained ramping bulkhead on the loading side and tandem axle portability.  New liners were installed in spring 2021.

· Smico 4’ x 10’ Single Deck Virgin Aggregate Scalping Screen.

· One (1) C.M.I. Portable Self-Erect 30” x nominal 47’ long Virgin Scale Conveyor with receiving trough, belt scale and wind guards on a single axle suspension.

· Portable Custom Welding straight drum measuring a nominal 9’-0” diameter x 43’ long and trunnions with Railroad Bearings replaced the 400 TPH triple drum shell in 2012.  This unit is equipped with a 5 HP slinger feed conveyor, Cradle Chain driven with 150 HP motor and Heavy-Duty Dodge TXT-10 reducer. The burner is a Hauck Starjet 580 long nose combination fuel burner currently burning natural gas.  Unit also includes a recycle entry collar, support stands to grade, and a quad axle suspension.  (52) NEW flights are included with the drum and the drum is skinned and insulated for maximum heat retention. The shell was 3/8” thick new and Ultrasonic thickness test shows it is still nearly 3/8” thick consistently throughout.

· Portable Custom Welding Dust-Eater Model BHP-80-1152, 80,000 ACFM Baghouse includes mounted fan with twin 125 HP drives, an integrally mounted inertial collector, drag slat bottom dust removal, auger dust removal with cross waste auger and triple axle suspension.  On-board pulse and main control panel as well as air compressor. Unit operated with a Variable Frequency Drive and was NEW in 2016. This has been running on natural gas since 2018.

· One (1) C.M.I. Model DF-15/20 Portable Direct Fired AC Tank. This is a 35,000-gallon split tank with a 15,000-gallon and a 20,000-gallon compartment. Each compartment is equipped with a level indicating system and one of the compartments has scavenger coils.  The tank features on-board AC unloading pump and a Hot Oil Fuel Preheater, and pump on pump style metering system installed new in 2020 (replaced the Coriolis meter – available if desired). Triple axle suspension.

· Hy-Way model #HYCGP-200 Hot Oil Heater.

· One (1) 15,000-gallon coil heated tank with containment mounted on a tandem axle trailer with a diesel fuel tank as well as a loading and unloading pump. The tank was used to store burner fuel and currently being used as a tack tank for job support.

· One (1) Portable Gencor® 30,000-gallon single compartment indirect fired AC Tank.

· Portable Custom Welding Model P2B-RAP Dual Bin RAP System consisting of two (2) 10’ x 14’ bins with 36” feeders, 7.5 HP AC drives, and mounted/removable grizzlies and UHMW wear liners.  Integral folding 36” wide x nominal 50’ long scale conveyor with gravity take-up and a 15 HP AC drive. Bin #1 is equipped with an air cannon and a bin vibrator and bin #2 includes a bin vibrator.  Unit features mounted bulkhead walls, a magnet mounted above the collector belt and tandem axle portability. This unit was NEW in 2014.

· GenTec Turbo RAP Gator lump breaker is mounted above the RAP Screen.

· Smico 4’ x 8’ Single Deck RAP Scalping Screen.

· One (1) Portable Self-Erect CMI Model PC2455 RAP Feed Conveyor, 24” wide x 55’ long with AC drive and gravity take-up with wind guards.

· One (1) C.M.I. Single Level Control House with 2020 Minds Drumtronics full automation control system with burner control and backup manual panel. Libra silo load out and scaling system. House is heated and cooled.

· One (1) Gencor®/Bituma® 70 Ton capacity Self-Erect Silo. Unit features a 36” wide x 46’ long main drag slat conveyor factory rated @ 450 TPH, single strand 6” pitch chain, electrically heated floor, a pneumatic reject system, and a 50 HP drive motor which has been freshly rebuilt.  The 70 Ton capacity silo is skinned and insulated and features electric heat strips on the cone. On-board air compressor operates the dual silo discharge gates. Silo scale loading is via load cells.

· One (1) Portable horizontal 750BBL Filler/Dust Silo System with twin screw conveyor auger system, dual fill ports, and baghouse style fill vent. Tandem axle portability.

· Spare Parts Trailer included.

**NOTE – plant is currently dismantled and ready for purchase!
